Description

Automatic Vacuum Forming and Cutting in One Production Line

The Full-Automatic Negative Pressure Thermoforming Machine with Cutting combines vacuum forming and cutting processes in one continuous automatic production line.

The machine integrates mechanical, electrical, and pneumatic systems and is controlled by a microcomputer and industrial PLC. Its user-friendly HMI touchscreen allows operators to monitor the production process and adjust operating parameters conveniently.

A far-infrared heating system heats the plastic sheet evenly before forming. The heated sheet is then shaped by negative pressure, accurately cut, automatically stacked, and counted. The integrated process reduces secondary handling, saves labor, minimizes product contamination, and improves overall production efficiency.

Automatic Production Process

The machine completes the following operations automatically:

Sheet feeding → Heating → Negative-pressure vacuum forming → Cooling → Cutting → Stacking → Automatic counting

Each section of the production line works together continuously, providing stable and efficient production of thermoformed plastic products.

Key Features

Integrated Forming and Cutting

Vacuum forming and cutting are completed within one production line, reducing the need for separate machines and additional product handling.

Negative-Pressure Forming Technology

The vacuum-forming system produces consistent shapes, smooth surfaces, and reliable product dimensions for a wide range of plastic packaging applications.

PLC and HMI Control

The complete machine is controlled by an industrial PLC and human-machine interface, allowing operators to set and monitor production parameters easily.

Far-Infrared Heating System

The heating system provides stable and even heat distribution across the plastic sheet, supporting consistent forming quality.

Automatic Stacking and Counting

Finished products are automatically stacked and counted, reducing manual labor and simplifying downstream packaging operations.

High Cutting Force

The integrated cutting station provides a maximum cutting force of 100 tons, helping achieve clean edges and accurate product separation.

Wide Forming Area

The machine is available with maximum forming areas of 850 × 750 mm or 950 × 750 mm, making it suitable for different mold and product sizes.

Reduced Manual Handling

Automatic feeding, forming, cutting, stacking, and counting reduce direct operator involvement and help prevent secondary contamination.

Reliable Industrial Operation

The machine offers stable functionality, convenient operation, strong automation, and reliable performance for continuous production environments.

Suitable Plastic Materials

The XG-B machine is suitable for thermoforming various thermoplastic sheets, including:

• HIPS
• PS
• PP
• PVC
• PET
• APET
• Other compatible thermoplastic sheets

Material suitability may vary according to sheet thickness, product depth, mold design, and production requirements.

Product Applications

The machine can be used to manufacture:

• Food packaging containers
• Fruit and vegetable trays
• Egg trays and packaging
• Bakery and cake containers
• Meat and seafood trays
• Plastic plates and bowls
• Disposable food trays
• Plastic lids and covers
• Cosmetic packaging
• Electronic component trays
• Industrial packaging trays
• Medical product packaging
• Transparent plastic boxes
• Round, square, shallow-draw and irregular-shaped products

Technical Specifications

Note

Machine specifications and configurations can be customized according to the customer’s product dimensions, plastic material, mold design, forming depth, and production requirements.
